Syntax Hexadecimal 0xFE 0x86
Decimal 254 134
Description This command deletes all touch regions previously created. It is
recommended that this command is issued before setting regions.
Remembered Yes
9.5 Set Touch Mode
Syntax Hexadecimal 0xFE 0x87 [mode]
Decimal 254 135 [mode]
Parameters Parameter Length Description
mode 1 Touch pad mode. Region mode is 0,
Co-ordinate mode is 1.
Description This commnad sets the reporting mode for the touch pad. Region mode
returns up and down values on press events within defined regions,
while Co-ordinate mode reports every event on the touch pad with
coordinates.
Remembered Yes
Default Co-ordinate Mode
9.6 Set Region Reporting Mode
Syntax Hexadecimal 0xFE 0x88 [mode]
Decimal 254 136 [mode]
Parameters Parameter Length Description
mode 1 Reporting mode for region press
events.
Description This command sets the reporting mode for touch events in region mode.
Defined key up and key down values will be sent only when certain
reporting parameters are set.
Bit Reporting Parameter
0 Press
1 Release
2 Drag
3 Out of Region
4-7 Reserved
Key down values are transmitted for press and drag events while
key up values are sent on releases. Any out of region touches will be
reported with 0xFF.
Remembered Yes
