Parameters Parameter Length Description
refID 1 A unique bitmap identification
number.
size 2 Bitmap file size (LSB to MSB).
data x Bitmap data.
Description The GLT24064 is capable of storing 128 font and bitmap files up to 16
Kbytes total. In order to upload a bitmap to the GLT24064 you must
first initiate the upload font file command (0xFE 0x5E), you must then
pass it a reference identification number, which must be unique for
every font on the display module. You may then pass the display
module the two byte file system size, which needs to be transfered LSB,
then MSB. This is almost always the entire 16kB, meaning the values
0x00 0x40 0x00 0x00 must be issued. The last part of uploading a
bitmap is transmitting the bitmap file data.
For detailed instructions on uploading a file to the GLT24064 see
Section 11 on page 43.
NOTE This command is available but not not supported in I 2 C.
Remembered Always
7.3 Drawing a Bitmap from Memory
Syntax Hexadecimal 0xFE 0x62 [refID] [X] [Y]
Decimal 254 98 [refID] [X] [Y]
ASCII 254 “b” [refID] [X] [Y]
Parameters Parameter Length Description
refID 1 The bitmap identification number.
X 1 Left bounds.
Y 1 Top bounds.
Description This command will draw a bitmap that is located in the on board
memory. The bitmap is referenced by the bitmaps reference
identification number, which is established when the bitmap is uploaded
to the display module. The bitmap will be drawn beginning at the top
left, from the specified X,Y coordinates. A directory listing of the
contents of the entire filesystem may be obtained by using the “Get
Filesystem Directory” command, see Section 11.5 on page 48 for more
detailed information.
Remembered No
