2 WIRING
Warning:
Wiring the positive side of the DC source to loads connected to outputs 1 through 8
and the negative side of the DC source to the output common(s) would create a Negative Logic
condition, which may be considered an unsafe practice under CE directives.
Signal
Pin
HSC600
I1 Input
1
I2 Input
2
I3 Input
3
I4 Input
4
I5 Input
5
I6 Input
6
I7 Input
7
I8 Input
8
C Common
1
Q1 Output
1
Q2 Output
2
Q3 Output
3
Q4 Output
4
Q5 Output
5
Q6 Output
6
Q7 Output
7
Q8 Output
8
VC Common
1
V+
Load Voltage +
1
Internally Connected
*
OCS Bottom View – Shows
Corresponding I/O Pin
I4
Q1
Q2
Q3
Q4
I5
I6
I7
I8
Q5
Q6
Q7
Q8
C
I1
I2
V+
I3
VC
0-24VDC
5-35VDC
LOAD
LOAD
LOAD
LOAD
LOAD
LOAD
LOAD
LOAD
001HSC001
*
