Metal Plastic SmartStack Digital Combo Modules
HE800DIQ611 HE-DIQ611 8 DC Inputs (12/24vdc, pos/neg logic), 8 DC Outputs (5/12/24vdc, 0.5A, neg logic with ESCP)
HE800DIQ612 HE-DIQ612 8 DC Inputs (12/24vdc, pos/neg logic), 6 Relay Outputs (250vac, 30vdc, 3.0A)
HE800DIQ616 HE-DIQ616 8 DC Inputs (12/24vdc, pos/neg logic), 8 DC Outputs (5/12/24vdc, 0.5A, pos logic with ESCP)
HE800DIQ622 HE-DIQ622 8 AC Inputs (120vac), 6 Relay Outputs (250vac, 30vdc, 3.0A)
HE800DIQ624 HE-DIQ624 8 AC Inputs (120vac), 8 AC Outputs (80-250vac, 0.5A)
HE800DIQ627 HE-DIQ627 8 AC Inputs (120/240vac), 8 AC Outputs (80-250vac, 2.0A)
HE800DIQ711 HE-DIQ711 16 DC Inputs (12/24vdc), 12 DC Outputs (5/12/24vdc, 0.5A neg. logic with ESCP)
HE800DIQ712 HE-DIQ712 14 DC Inputs (12/24vdc), 10 Relay Outputs (250vac, 30vdc, 3.0A)
HE800DIQ716 HE-DIQ716 16 DC Inputs (12/24vdc), 12 DC Outputs (10-28vdc, 0.5A pos. logic with ESCP)
HE800DIQ722 HE-DIQ722 14 AC Inputs (120vac), 10 Relay Outputs (250vac, 30vdc, 3.0A)
HE800DIQ935 HE-DIQ935 32 DC Inputs (24vdc pos logic), 40 DC Outputs (5/12/24vdc, 50mA, neg logic)
Recommended for pushbutton/pilot light duty.
Metal Plastic SmartStack Digital I/O Modules
HE800DIM210 HE-DIM210 8 DC Inputs (12/24vdc, pos/neg logic)
HE800DIM310 HE-DIM310 16 DC Inputs (12/24vdc, pos/neg logic)
HE800DIM410 HE-DIM410 32 DC Inputs (12/24vdc, pos/neg logic)
HE800DQM202 HE-DQM202 8 Relay Outputs (250vac, 30vdc, 4.0A)
HE800DQM902 HE-DQM902 20 Relay Outputs (250vac, 30vdc, 2.5A)
HE800DQM306 HE-DQM306 16 DC Outputs (12/24vdc, 0.5A pos logic with ESCP)
HE800DQM406 HE-DQM406 32 DC Outputs (12/24vdc, 0.5A pos logic with ESCP)
Metal Plastic SmartStack Analog Input Modules
HE800ADC020 HE-ADC020 2 channel Analog Inputs, Current (0-20mA, +/-20mA)
HE800ADC120 HE-ADC120 4 channel Analog Inputs, Current (0-20mA, +/-20mA)
HE800ADC010 HE-ADC010 2 channel Analog Inputs,Voltage (0-5vdc, +/-5vdc, 0-10vdc, +/-10vdc)
HE800ADC110 HE-ADC110 4 channel Analog Inputs,Voltage (0-5vdc, +/-5vdc, 0-10vdc, +/-10vdc)
HE800ADC920 HE-ADC920 12 channel Analog Inputs (4-20mA, 0-5vdc, thermistor) ch-by-ch selectable
HE800THM000 HE-THM000 2 channel Thermocouple Inputs (J, K,T, E, C, R, S,+/-25mV, +-50mV, +/-100mV)
HE800THM100 HE-THM100 4 channel Thermocouple Inputs (J, K,T, E, C, R, S,+/-25mV, +-50mV, +/-100mV)
HE800THM200 HE-THM200 8 channel Thermocouple Inputs (J,K,T,E, C, R, S,+/-25mV, +-50mV, +/-100mV)
HE800RTD000 HE-RTD000 2 channel RTD Inputs (Pt-100, Pt-200, Pt-500, Pt-1000)
HE800RTD100 HE-RTD100 4 channel RTD Inputs (Pt-100, Pt-200, Pt-500, Pt-1000)
Metal Plastic SmartStack Analog Output Modules
HE800DAC002 HE-DAC002 2 channel Analog Outputs, Current (4-20mA)
HE800DAC102 HE-DAC102 4 channel Analog Outputs, Current (4-20mA)
HE800DAC001 HE-DAC001 2 channel Analog Outputs,Voltage (+/- 10vdc)
HE800DAC101 HE-DAC101 4 channel Analog Outputs,Voltage (+/- 10vdc)
HE800DAC106 HE-DAC106 4 channel Analog Outputs, Sourcing (0-20mA)
HE800DAC202 HE-DAC202 8 channel Analog Outputs, Current (0-20mA, +/- 10vdc) ch-by-ch selectable
Metal Plastic SmartStack Mixed Discrete and Analog Modules
HE800MIX111 HE-MIX111 2 channel Voltage (+/- vdc) Inputs, 2 channel Voltage (+/-10vdc) Outputs
HE800MIX122 HE-MIX122 2 channel Current (+/- 20mA) Inputs, 2 channel Current (0-20mA) Outputs
HE800MIX126 HE-MIX126 12-bit, 2 channel Current (0-20mA) Inputs, 2 channel Current sourcing (0-20mA) Outputs
HE800MIX211 HE-MIX211 14-bit ISOLATED, 4 channel Voltage (+/-10vdc) Inputs, 14-bit ISOLATED 2 channel Voltage (+/-10vdc) Outputs
HE800MIX901 HE-MIX901 8 DC Inputs (12/24vdc), 8 DC Outputs (12/24vdc, 0.5A pos. logic with ESCP) and 4 channels Analog
Inputs, voltage (+/-10vdc), 12 bit; 2 channels Analog Outputs, voltage (+/- 10vdc)
HE800MIX902 HE-MIX902 8 DC Inputs (12/24vdc), 8 DC Outputs (12/24vdc, 0.5A pos. logic with ESCP) and 4 channels Analog
Inputs, current (0-20ma, 4-20ma), 12 bit; 2 channels Analog Outputs, current (4-20ma)
HE800MIX906 HE-MIX906 8 DC Inputs (12/24vdc), 8 DC Outputs (5/12/24vdc,0.5A pos. logic with ESCP) and 4 channels Analog
Inputs, current (0-20ma, 4-20ma), 12 bit; 2 channels Analog Outputs, current sourcing (4-20ma)
HE800MIX912 HE-MIX912 8 DC Inputs (12/24vdc), 8 DC Outputs (12/24vdc,0.5A pos. logic with ESCP) and 4 ISOLATED (1000V)
channels Analog Inputs, current (0-20ma, 4-20ma), 12 bit; 2 channels ISOLATED (1000V) Analog Outputs,
current (4-20ma)
HE800MIX963 HE-MIX963 Temperature Controller I/O Board. 4 temperature Inputs (RTD/Thermocouple) selectable ch-by-ch,
2 channels Analog Outputs, current (4-20mA), 2 Relay Outputs (250vac, 30vdc, 10A), 2-SSR Drive Outputs
Metal Plastic SmartStack I/O Expansion Module
HE800FOX100 Not Available SmartStack I/O Expansion Module. Interfaces to fiber optic FOX I/O System.
Order fiber optic cables separately. Can only be used with OCS110, OCS210, RCS116, RCS250, or
OCS250 models.
Many I/O
Options
Fieldbus
Networks
Ethernet
Communication
Selection Guide
Plastic SmartStack I/O
Horner APG
USA 877-665-5666 or 317-916-4274
Europe (+353) 21-4321266
www.hornerOCS.com
