MAN0869-06-EN

Specifications / Installation

__________________________________________________________________________________________________________________________________________________________________
12/17/2008

Page 2 of 4 ECN # 947



























4

Wiring and Jumpers


Wire according to the type of inputs / outputs used, and select the
appropriate jumper option.































4.1 Wiring

Examples

J1 Orange
Terminal
Connector

Name

I1 IN1
I2 IN2
I3 IN3
I4 IN4
I5 IN5
I6 IN6
I7 IN7
I8 IN8

H1 HSC1

/IN9

0V Ground
A1 Analog

IN1

A2 Analog

IN2

A3 Analog

IN3

A4 Analog

IN4

0V Ground










4.2

Wiring Examples (continued)


J2 Black

Terminal

Connector

Name

C6

Relay 6 COM

R6

Relay 6 NO

C5

Relay 5 COM

R5

Relay 5 NO

C4

Relay 4 COM

R4

Relay 4 NO

C3

Relay 3 COM

R3

Relay 3 NO

C2

Relay 2 COM

R2

Relay 2 NO

C1

Relay 1 COM

R1

Relay 1 NO

H4

HSC4 / IN12

H3

HSC3 / IN11

H2

HSC2 / IN10







4.3

I/O Jumpers Settings (JP1 - JP2)




















4.4

External DIP Switch Settings























Note: The Cscape Module Setup configuration must match the

selected I/O (JP) jumper settings.

JP1 Digital DC In / HSC

Positive Negative

Logic Logic

Default

A1
A2
A3
A4

JP2 Analog In (A1 – A4)

Current Voltage

(20 mA) (10 V)

Default

J1

JP2

JP1

J2

001XLE025

Location of I/O jumpers (JP)

and wiring connectors

(J1 and J2).

I1

0V

001XLE036

12-24VDC

I1

0V

Positive Logic In Negative Logic In

Positive Logic vs. Negative Logic Wiring

The XLt can be wired for Positive Logic inputs or

Negative Logic inputs.

001XLE015

0V ON J1

12-24VDC

R2

C2

R3

C3

R6

C6

R4

C4

R5

C5

R1

C1

H4

H2

H3

LOAD

230VAC

OR

25VDC

N

L

LOAD

230VAC

OR

25VDC

N

L

LOAD

230VAC

OR

25VDC

N

L

LOAD

230VAC

OR

25VDC

N

L

LOAD

230VAC

OR

25VDC

N

L

LOAD

230VAC

OR

25VDC

N

L

J2 Black

Positive Logic

Digital In / Relay Out

Wiring Specifications

ŠFor I/O wiring (discrete), use the

following wire type or equivalent:

Belden 9918, 18 AWG (0.8 mm

2

)

or larger.

ŠFor shielded Analog I/O wiring,

use the following wire type or

equivalent: Belden 8441, 18

AWG (0.8 mm

2

) or larger.

ŠFor CAN wiring, use the

following wire type or equivalent:

Belden 3084, 24 AWG (0.2 mm

2

)

or larger.

Use copper conductors in field

i i

l

60/75° C


The External DIP Switches are
used for termination of the RS-485
ports. The XLt is shipped un-
terminated.

To terminate, select one of the
jumpers shipped with the product
and insert it based upon the option
that is desired or, select the switch
and configure based upon the
option that is desired.

As seen when looking at the top of the XLt unit

XT102 J1 Orange

Positive Logic In

Digital In /

Analog In

I1

I2

I3

I4

0V

A1

A2

0V

I5

I6

I7

I8

A3

A4

H1

001XLE017

12-24VDC

LOOP PWR

20mA

0-10VDC

Note:
When using JP2 (A1-A4), e

ach

channel can be independently
configured.

Note:
Loop Power requirements are determined
by the transmitter specification.

Pin

MJ1 Pins

MJ2 Pins

Signal

Direction

Signal

Direction

8

TXD OUT TXD OUT

7

RXD IN RXD IN

6

0 V

Ground

0 V

Ground

5*

+5

60mA

OUT

+5

60mA

OUT

4

RTS OUT TX- OUT

3

CTS IN TX+ OUT

2

RX- /

TX-

IN / OUT

RX-

IN

1

RX+ /

TX+

IN / OUT

RX+

IN

1

8

Serial Communications:
MJ1
: (RS-232 / RS-485) Use for Cscape programming and
Application-Defined Communications.

MJ2:
(RS-232 / RS-485) Use for Application-Defined
Communications.

DIPSW3: FACTORY USE
ONLY (tiny bootloader
firmware downloading).
NOT TO BE USED FOR
NORMAL OCS
OPERATION.

DIPSW2: MJ2 Termination
(default – none)

DIPSW1: MJ1 Termination
(default – none)

001XLE037-R1

* +5Vdc 60mA Max
