53
Autopan, Preset, Patrol
250 max preset selectable (VIDEOTEC Macro Protocol)
15 characters string for Area and Preset titling
15.4 Communications
Configuration through OSD
RS232 interface for PC control set-up and firmware
upgrade
Two RS485 ports for daisy chain configuration
Addressable through dip-switch up 255 units
15.5 Protocols
AMERICAN DYNAMICS, PANASONIC, PELCO D, VIDEOTEC
MACRO, VISTA
AMERICAN DYNAMICS, PANASONIC, PELCO, VISTA are registered trademarks.
The product may be interfaced with devices not manufactured by
VIDEOTEC. It is possible that the interface protocols have changed or are in
a different configuration from earlier tested units by VIDEOTEC. VIDEOTEC
recommends a test prior to installation. VIDEOTEC will not be liable for
any installation costs or lost revenues in the event a compatibility problem
will occur.
15.6 Environment
Indoor / Outdoor
Operating temperature with heater. -10°C / +60°C (+14°F
/ +140°F)
Improved surge immunity: up to 2KV line to line, up to
4KV line to earth (Class 4), to achieve a better protection
from lightning
15.7 Certifications
CE EN60950-1, EN61000-6-3 and EN50130-4
FCC part 15, Class B
IP66 EN60529
15 Technical specifications
h The installation is type TNV-1, do not
connect it to SELV circuits.
h In order to reduce the risk of fire, only use
cable sizes greater than or equal to 26AWG.
15.1 General
Built in aluminium and ABS
Epoxypolyester powder painting, RAL9002 colour
Top mount (OTT)
Transmission through toothed belt
Electronic limit switches
Plug installation thanks to connector and easy
replacement on-site
Zero backlash
Max weight camera+lens 4,5kg (9.9lb)
Optical encoders for absolute positioning
15.2 Mechanical
3 cable glands M16
Horizontal continuous rotation
Vertical rotation +45° to -20°
Variable pan speed: from 0.02° up to 20°/s
Variable tilt speed: from 0.02° up to 20°/s
Internal usable area: see drawings
Unit weight30kg / 66.1lb
Glass window (WxH): 112x95mm (4.4x3.7in)
Preset accuracy: 0.02°
15.3 Electrical/video
Input voltage:
- 230Vac, 50/60Hz, 100W
- 24Vac, 50/60Hz, 100W
Absorbed current:
- 230Vac, 0.4A
- 24Vac, 4A
Dimensions of input cables: AWG 16 (24Vac) -18
(120/230Vac)
Dimensions of signal cables: AWG 20-26
Alarm input: 10-35Vdc
Dry contacts: max 50Vdc or 30Vac @ 1A
Video line: coaxial cable (1Vpp, 75Ohm)
Housing standard heater 24Vac, 20W max
Housing wiper: 24Vac, 50/60Hz, 7W consumption max
Camera power supply: 12Vdc, 800mA
Lens power supply: 6-15Vdc, max 200mA
Lenses control: polarity inversion and common wire
