Setup:
NOTE:
It is strongly reccomended that the user cycles power to the PowerLine module after saving any
program changes to ensure that the setting alterations take place and any old setting data is erased by
the controller.
From this screen, the user has access to all of the setup sub-screens and drop downs that will enable the
configuration of the particular control logic mode that has been selected. The following pages describe the
setting available, their limits and what the effect is on the application being worked on.
NOTE:
Each Graphical User Interface screen may have grayed out settings or look different to the pictures
shown in this manual. This is due to the settings regarding the mode of operation and or other user
settings that may render them invalid or require them to be set to a mandatory set point.
