PowerLine System Controller User Guide
Page | 10
PowerLine User Guide
Valve Type
Coil
Voltage
Imin (mA)
Imax (mA)
Dither
Frequency
Dither
Amplitude
DAAL, DBAL, DLDA, DMDA, DNDA,
DNDC, DTCA, DTDA, DWDA, FMDA,
FMDB, PRDL, PRDM, PRDN, PRDP,
RBAN, RBAP
12
1150mA
100 –
250Hz
dependant on
valve size
DAAL, DBAL, DLDA, DMDA, DNDA,
DNDC, DTCA, DTDA, DWDA, FMDA,
FMDB, PRDL, PRDM, PRDN, PRDP,
RBAN, RBAP
24
590
100 –
250Hz
dependant on
valve size
Note: Final optimized settings are valve size and system/application dependent. Consult valve manufacturer for full details
as required
.
Valve Type
Coil
Voltage
Imin (mA)
Imax (mA)
Dither
Frequency
Dither
Amplitude
HPV – 02 – E1
12
~440 – 460
~810 - 1200
100 Hz
HPV – 02 – E1
24
~215 – 235
~410 – 600
100 Hz
Note: Final optimized settings are valve size and system/application dependent. Consult valve manufacturer for full details
as required
.
Valve Type
Coil
Voltage
Imin (mA)
Imax (mA)
Dither
Frequency
Dither
Amplitude
PRM2-04
12
~600-700
~1700
90
0-30
PRM2-04
24
~250-270
~800
60
0-30
PRM2-06
12
~700-850
~2500
90
0-30
PRM2-06
24
~270-310
~1000
60
0-30
PVRM1-063/S
12
~250-310
~1000-1200
100
-
PP2P-06
12
~300-330
~1000-1100
150
-
PRM6-10
12
~600-700
~1900
90
0-30
PRM6-10
24
~300-400
~1100
60
0-30
PVRM3-10
12
~250-290
~1500
100
-
SR4P-B2
12
~150-210
~1000
160
SR4P-B2
24
~150-210
~750
160
Note: Final optimized settings are valve size and system/application dependent. Consult valve manufacturer for full details
as required
.
