1. DISPLAY: 5 digit LCD 0.48" (12.2 mm) high digits
CUB5TCR0: Reflective LCD with full viewing angle
CUB5TCB0: Transmissive LCD with selectable red or green LED backlight,
viewing angle optimized. Display color change capability with output state
when using an output module.
2. POWER: Input voltage range is +9 to +28 VDC with short circuit and input
polarity protection. Must use an RLC model MLPS or an NEC Class 2 or
Limited Power Source (LPS) rated power supply.
3. READOUT:
Resolution: 1 or 0.1 degrees
Scale: °F or °C
Offset Range: -999 to 9999 display units
4. THERMOCOUPLE INPUTS:
Isolation: TC+ and TC- terminals are not electrically isolated from the power
supply or optional comms cards.
Open Sensor Display:

Overrange/Underrange Input: 
/
Overrange/Underrange Display : “ ..... ”/“- ..... ”
Maximum Input Voltage: 30 VDC, TC+ to TC-
Maximum Input Voltage TC-: 3 VDC max. with respect to common
*After 20 min. warm-up. Accuracy is specified in two ways: Accuracy at
23°C and 15 to 75% RH environment; and Accuracy over a -35 to 75°C and 0
to 85% RH (non condensing) environment. Accuracy specified over the -35 to
75°C operating range includes meter tempco and cold junction tracking effects.
The specification includes the A/D conversion errors, linearization conformity,
and thermocouple cold junction compensation. Total system accuracy is the sum
of meter and probe errors. Accuracy may be improved by field calibrating the
meter readout at the temperature of interest.
5. RESPONSE TIME:
Display: 500 msec min.
Output: 800 msec max (with input filter setting of 0)
6. USER INPUT (USR): Programmable input. Connect terminal to common
(USR COMM) to activate function. Internal 10KΩ pull-up resistor to +9 to
28 VDC.
Threshold Levels: V
IL
= 0.7 V max; V
IH
= 2.4 V min; V
MAX
= 28 VDC
Response Time: 5 msec typ.; 50 msec debounce (activation and release)
7. CERTIFICATIONS AND COMPLIANCES:
CE Approved
EN 61326-1 Immunity to Industrial Locations
Emission CISPR 11 Class A
IEC/EN 61010-1
RoHS Compliant
UL Recognized Component: File #E179259
UL Listed: File #E137808
Type 4X Outdoor Enclosure rating (Face only)
IP65 Enclosure rating (Face only)
IP20 Enclosure rating (Rear of unit)
Refer to EMC Installation Guidelines for additional information.
8. MEMORY: Nonvolatile E 2 PROM memory retains all programming
parameters and max/min values when power is removed.
9. CONNECTIONS: Wire clamping screw terminals
Wire Strip Length: 0.3" (7.5 mm)
Wire Gage: 30-14 AWG copper wire
Torque: 5 inch-lbs (0.565 N-m) max.
10. ENVIRONMENTAL CONDITIONS:
Operating Temperature Range for CUB5TCR0: -35 to 75°C
Operating Temperature Range for CUB5TCB0 depends on display color
and intensity level as per below:
INTENSITY LEVEL TEMPERATURE
Red Display 1 & 2 -35 to 75°C
3 -35 to 70°C
4 -35 to 60°C
5 -35 to 50°C
Green Display 1 & 2 -35 to 75°C
3 -35 to 65°C
4 -35 to 50°C
5 -35 to 35°C
Storage Temperature: -35 to 85°C
Operating and Storage Humidity: 0 to 85% max. relative humidity (non-
condensing)
Vibration to IEC 68-2-6: Operational 5-500 Hz, 5 g
Shock to IEC 68-2-27: Operational 30 g
Altitude: Up to 2000 meters
11. CONSTRUCTION: This unit is rated for NEMA 4X/IP65 requirements for
outdoor use. Installation Category I, Pollution Degree 2. High impact plastic
case with clear viewing window. Panel gasket and mounting clip included.
12. WEIGHT: 3.2 oz (100 g)
2
G
eneral
M
eter
S
pecificationS
o
rderinG
i
nforMation
MODEL
NO.
DISPLAY COLOR
INPUT CURRENT
@ 9 VDC WITHOUT
CUB5RLY0
INPUT CURRENT
@ 9 VDC WITH
CUB5RLY0
CUB5TCR0 --- 10 mA 40 mA
CUB5TCB0 Red (max intensity) 85 mA 115 mA
CUB5TCB0 Green (max intensity) 95 mA 125 mA
ACCURACY
@ -35 to 75°C
± °C
0.08 mV
5.8
8.1
4.9
42.6<540 ° C
15.0>540 ° C
15.0
no
standard
no
standard
0.02 mV -10.00 to 65.00 mV
(+) brown
(-) blue
(+) yellow
(-) red
2.3
-200 to 1372°C
-328 to 2502°F
K
(+) orange
(-) blue
(+) orange
(-) red
2.8
-200 to 1300°C
-328 to 2372°F
N
(+) brown
(-) blue
(+) purple
(-) red
2.7
-200 to 871°C
-328 to 1600°F
E
no
standard
no
standard
9.1<540 ° C
4.5>540 ° C
200 to 1820°C
392 to 3308°F
B
(+) white
(-) blue
no
standard
4.5
-50 to 1768°C
-58 to 3214°F
S
(+) white
(-) blue
no
standard
4.5
-50 to 1768°C
-58 to 3214°F
R
(+) yellow
(-) blue
(+) white
(-) red
1.9
-200 to 760°C
-328 to 1400°F
J
(+) white
(-) blue
(+) blue
(-) red
2.3
-200 to 400°C
-328 to 752°F
T
BS 1843 ANSI
15.0
4.3
5.8
ACCURACY
@ 23°C
± °C
RANGE TC TYPE
WIRE COLOR
TYPE MODEL NO. DESCRIPTION PART NUMBER
CUB5 CUB5TC
Thermocouple Meter with Reflective Display CUB5TCR0
Thermocouple Meter with Backlight Display CUB5TCB0
Optional Plug-in Cards
CUB5RLY Single Relay Option Card CUB5RLY0
CUB5SNK Dual Sinking Open Collector Output card CUB5SNK0
CUB5COM
RS485 Serial Communications Card CUB5COM1
RS232 Serial Communications Card CUB5COM2
CUB5USB USB Programming Card CUB5USB0
Accessories
MLPS
+12 VDC Micro-Line Power Supply, 85 to 250 VAC source, 400 mA max out MLPS1000
+24 VDC Micro-Line Power Supply, 85 to 250 VAC source, 200 mA max out MLPS2000
CBLPROG Programming Cable RS232 (RJ11-DB9) CBLPROG0
CBPRO Programming Cable RS485 (RJ11-DB9) CBPRO007
SFCRD Crimson PC Configuration Software for Windows 98, ME, 2000, XP 1 SFCRD200
CBLUSB USB Programming Cable CBLUSB00
1 Crimson software is a free download from http://www.redlion.net
