2
Ordering Information . . . . . . . . . . . . . . . . . . . 2
General Meter Specifications . . . . . . . . . . . . . 3
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Optional Plug-In Cards . . . . . . . . . . . . . . . . . . 4
Installing the Meter . . . . . . . . . . . . . . . . . . . . . 5
Setting the Jumpers . . . . . . . . . . . . . . . . . . . . 5
Installing Plug-In Cards . . . . . . . . . . . . . . . . . . 6
Wiring the Meter . . . . . . . . . . . . . . . . . . . . . . . 6
Reviewing the Front Buttons and Display . . . . 8
Programming the Meter. . . . . . . . . . . . . . . . . . 9
Factory Service Operations . . . . . . . . . . . . . 27
Troubleshooting Guide . . . . . . . . . . . . . . . . . 28
Parameter Value Chart . . . . . . . . . . . . . . . . . 28
Programming Overview . . . . . . . . . . . . . . . . 30
T
able
O
f
C
OnTenTs
O
rdering
i
nfOrmaTiOn
PAX 0
DP - Dual Process Input
0 - Red, Sunlight Readable Display
0 - 85 to 250 VAC
1 - 18 to 36 VDC, 24 VAC
Meter Part Numbers
Option Card and Accessories Part Numbers
TYPE MODEL NO. DESCRIPTION PART NUMBER
Optional
Plug-In
Cards
PAXCDS
Dual Setpoint Relay Output Card PAXCDS10
Quad Setpoint Relay Output Card PAXCDS20
Quad Setpoint Sinking Open Collector Output Card PAXCDS30
Quad Setpoint Sourcing Open Collector Output Card PAXCDS40
PAXCDC
RS485 Serial Communications Card with Terminal Block PAXCDC10
Extended RS485 Serial Communications Card with Dual RJ11 Connector PAXCDC1C
RS232 Serial Communications Card with Terminal Block PAXCDC20
Extended RS232 Serial Communications Card with 9 Pin D Connector PAXCDC2C
DeviceNet Communications Card PAXCDC30
Profibus-DP Communications Card PAXCDC50
PAXCDL Analog Output Card PAXCDL10
PAXUSB PAX USB Programming Card (Not included in PAX product UL E179259 file) PAXUSB00
Accessories
CBLUSB USB Programming Cable Type A-Mini B CBLUSB01
ICM8 Ethernet Gateway ICM80000
PAXLBK Units Label Kit Accessory PAXLBK10
SFCRD * Crimson PC Configuration Software for Windows 98, ME, 2000 and XP SFCRD200
Notes:
1. For Modbus communications use RS485 Communications Output Card and configure communication (  ) parameter for Modbus.
2. Crimson ® 2 software is available as a free download at http://www.redlion.net/
