5
10.197 (259.0)
7.931
(201.4)
4X R.10 (2.5)
MAX.
All tolerances ±.059" (±1.5 mm)
PANEL CUT-OUT
.87
(22.1)
2.95 (75)
1.48 (37.5)
2.95
(75)
VESA MOUNT (MIS-D 75) DIMENSIONS
G10
11.458 (291.0)
7.561
(192.0) 4X R.10 (2.5)
MAX.
All tolerances ±.059" (±1.5 mm)
PANEL CUT-OUT
2.95 (75)
1.48 (37.5)
1.08
(27.4)
2.95
(75)
VESA MOUNT (MIS-D 75) DIMENSIONS
G12
13.390 (340.1)
10.457
(265.6)
4X R.10 (2.5)
MAX.
All tolerances ±.059" (±1.5 mm)
PANEL CUT-OUT
2.95 (75)
1.48 (37.5)
.09
(2.4)
2.95
(75)
VESA MOUNT (MIS-D 75) DIMENSIONS
G15
