Red Lion G15 15" LCD color touch panel - Manual (Page 3)

3
D
imenSionS
i
n
inches (mm)
(MOUNTING CLIPS INSTALLED)
5.51
(139.9)
7.70 (195.5) 2.00 (50.8)
5.7
(146)
7.9 (202)
2.97 (76)
Module sold
separately
G07
2.06 (52.4) 10.06 (255.6)
6.47
(164.4)
6.7
(171)
(MOUNTING CLIPS INSTALLED)
10.3 (262)
2.97 (76)
Module sold
separately
G09
10.84 (275.2)
8.57
(217.7)
2.06 (52.4)
8.8
(224)
(MOUNTING CLIPS INSTALLED)
11.1 (281)
2.97 (76)
Module sold
separately
12.10 (307.3)
8.20
(208.3)
2.06 (52.4)
8.4
(215)
(MOUNTING CLIPS INSTALLED)
12.3 (314)
2.97 (76)
Module sold
separately
11.10
(281.8)
14.03 (356.3)
2.14 (54.3)
11.3
(288)
(MOUNTING CLIPS INSTALLED)
14.3 (363)
2.97 (76)
Module sold
separately
G10
G15
G12
