Specifications

13

Specifications

General

Sensor Type . . . . . . . . . . . . . . . . . . . . . . . . . . Tipping bucket with magnetic reed switch
Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Contact closure
Attached Cable Length . . . . . . . . . . . . . . . . . . 40’ (12 m)
Cable Type . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-conductor, 26 AWG
Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . Modular connector (RJ-11)
Recommended Maximum Cable Length . . . . 900’ (270 m)
Housing Material. . . . . . . . . . . . . . . . . . . . . . . UV-stabilized ABS plastic

Dimensions
Rain Collector . . . . . . . . . . . . . . . . . . . . 8.75" diameter x 9.5" high (16.5 cm diameter

x 24 cm high)

Collection Area . . . . . . . . . . . . . . . . . . . 33.2 in

2

(214 cm

2

)

Weight . . . . . . . . . . . . . . . . . . . . . . . . . . 2 lbs. 3 oz. (1 kg)

Console Data

These specifications apply to sensor output as converted by Davis Instruments
weather station consoles.

Range

Daily Rainfall . . . . . . . . . . . . . . . . . . . . . 0.00” to 99.99” (0.0 mm to 999.8 mm)
Total Rainfall . . . . . . . . . . . . . . . . . . . . . 0.00” to 99.99” (0.0 mm to 9999 mm)

Accuracy

Rainfall . . . . . . . . . . . . . . . . . . . . . . . . . ±3%, ±1 rainfall count between 0.01" and

2.00" per hour (0.2 mm and 50.0

mm per

hour); ±5%, ±1 rainfall count between 2.00"
and 4.00" per hour (50.0 mm and 100.0

mm

per hour)

Resolution . . . . . . . . . . . . . . . . . . . . . . . 0.01” (0.2 mm)
Sample and Display Update Interval. . . 16 seconds (max)

WeatherLink

®

Data

These specifications apply to sensor output as logged and displayed by the
WeatherLink.

Daily Rainfall. . . . . . . . . . . . . . . . . . . . . . . . . . Total during archive interval
Total Rainfall. . . . . . . . . . . . . . . . . . . . . . . . . . Total during archive interval
Rate of Rainfall . . . . . . . . . . . . . . . . . . . . . . . . Maximum value during archive interval (For

Vantage Pro and Pro2 models only)

Input/Output Connections

Red . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Switch terminal
Green & Yellow. . . . . . . . . . . . . . . . . . . . . . . . Switch terminal
