Page 36
User's Guide 36
Setup Feature and Value List
FEATURE NAME
VALUE RANGE
DESCRIPTION
Media Type
[ Direct Thermal, Thermal
Transfer ]
Set to Thermal Transfer if ribbon
is used.
Media Sensing
[Gap, Continuous, Black Bar ]
Set to match media sensing
method.
Calibrate Media
(Form Length / Gap Length)
automatically displayed and are
not adjustable from this feature.
Pressing CANCEL initiates the
media calibration. The detected
media length and Gap are
displayed. Not required when
Media Sensing is set to
Continuous
Sensor Threshold
[ 0-255]
Automatically set by Calibration
mode.
Media Length
[ 0.25 - 12.00] (Inches)
Automatically set by Calibration
mode
Media Width
[ 0.5 - 4.05] (Inches, 4602)
[ 0.5 - 4.25] (Inches, 4603)
Set to media width used.
Present Distance
[ 0.00 - 1.00 ] (Inches)
Adjust to position label at tear
bar. If optional Peel and Present
kit is installed, this feature will
specify how far the label is
presented.
Present Sensor
[Enable, Disable]
This feature controls the
operation of the optional present
sensor. When installed and
enabled, the printer suspends
printing after each label until it is
removed by the operator. This
is typically used when the peel
and present option is installed
but could also be used with the
tear bar.
