2-15
2.8 BUTTON FUNCTIONS
WTM buttons are multi-functional and produce different
results depending on the system status (i.e., ON, OFF) and
how the buttons are pressed. See Tables 2-3 and 2-4.
Table 2-3 PWR Button Operation
System
Status
How Button is Pressed Result
OFF
Press, wait 2 to 5 seconds
for system prompt, then
press again
Turns on WTM
(see section 2.7)
ON
Press (and hold) for about 3
seconds until display screen
turns off
Turns off WTM
(see section 2.7)
ON Single tap
Calls up Main
Menu
ON
Menu Displayed
Single tap
Activates the
highlighted menu
item
Table 2-4 UP / DOWN Button Operation
System
Status
How Button is
Pressed
Result
ON
Menu Displayed
Single tap
(either button)
Scrolls through the menu
items
ON
Menu NOT
Displayed
Single tap
(either button)
Calls up gain control
(see section 2.11)
ON
Menu NOT
Displayed
Press and hold
both buttons
simultaneously
Initiates a calibration
(see section 2.9)
