EZ-Guide® Plus Lightbar Guidance System
Quick Reference Card
A
www.EZ-Guide.com
QUICK START: GETTING GUIDANCE
Reset guidance:
Define a guidance line:
Select a guidance pattern:
Drive with guidance:
A
B
Load an existing guidance line:
LEDs
When the three green LEDs in the center of
the lightbar are illuminated, you
are online.
Guidance line
The arrow represents your vehicle.
Steer the vehicle so the arrow moves
along the guidance line.
DRIVING WITH GUIDANCE
Pause
Need to pause guidance? Just select
the Pause icon (2) and then press
o
.
When you move, a dotted line guides you
back to the paused position. Then select 2
to resume guidance.
Status text
The status text shows information like how
far offline you are and
the number of the
swath that you are on.
