Product Overview
The GPS1000/GPS1000+/GPS1100 is an all in the antenna DGPS
receiver that provides position data for operations that do not require sub-
meter position accuracy or guidance. The GPS1000/GPS1000+/GPS1100
utilizes differential correction from the WAAS satellite differential
system. The GPS1000/GPS1000+/GPS1100 provides 2-meter accuracy
when using WAAS differential and 4 meter accuracy without any
differential correction.
The GPS1000/GPS1000+/GPS1100 is a valuable addition for general
data logging such as soil sample collection, scouting, and site verification
or as a GPS receiver for yield mapping.
The GPS1000+/GPS1100 has the ability to output a radar speed signal
into your controller or other equipment that accepts radar speed input.
Adaptor cables are available through Ag Leader Technology for Hiniker,
Raven, and Dickey-John radar guns.
The GPS1100 has the ability to be used in a Direct Command
application requiring a higher output rate. The GPS 1100 is
defaulted to output 1hz, but can be configured to output 4hz as
needed for Direct Command/Autoswath applications (See GPS 1100
Utility section). Four positions per second are outputted per second
using GGA and VTG NMEA messages with this configuration.
The GPS1000/GPS1000+/GPS1100 is weatherproof and protected
against power surges that are common on agricultural equipment. The
GPS1000/GPS1000+/GPS1100 is also backed by a 2-year warranty.
*NOTE – The GPS 1100 default configuration of 4800
1Hz is set to work with all Ag Leader monitors YM2000,
PF3000/3000Pro/Advantage and Insight.) If the
intended use of the GPS 1100 is for Direct Command,
which requires a higher output rate, the GPS 1100
WILL HAVE TO BE CONFIGURED TO DO SO. See
page 8 for instructions on how to configure the GPS
1100
