3000021 12
Radar Speed
Output
The GPS1000+/GPS1100 is capable of outputting a simulated radar
speed pulse. This simulates a similar pulse output that you would receive
from a standard radar gun. The GPS1000+/GPS1100 provides the
capability to provide simulated radar speed to your YM2000, PF3000,
PF3000 Pro, PF Advantage, or Insight display. To use the radar speed
input with an Ag Leader display, you must set the speed input to
RADAR under the appropriate setup screen for the monitor/display.
Additional cables will also be required to obtain the simulated speed
output. Contact Ag Leader’s Technical support team for these additional
cables.
*NOTE – The GPS1000 is not capable of simulated radar speed output.
Radar Speed
Compatibility
Adaptor cables are available through Ag Leader Technology for the
following three radar gun brands Dickey-John, Raven, and Hiniker.
These adaptor cables provide the ability to use the GPS1000+/GPS1100
in place of a radar gun. If using the GPS1000+/GPS1100 as a stand-
alone antenna, you will need to obtain an Auxiliary Power/Data Cable,
GPS power supply cable listed on page 15, and the appropriate Radar
Speed Adaptor Cable.
Radar Speed
Default Settings
The default output parameter provided in the GPS1000+/GPS1100 is a
minimum output speed of .5 MPH, meaning speed pulses will not be
output below this speed. The default radar pulse output rate is 45 Hz per
MPH.
Radar Speed Adaptor Cable Name Part Number
Hiniker adaptor cable 3000478
Raven adaptor cable 3000479
Dickey John adaptor cable 3000480
