GPS 1000 Plus Specifications
Ag Leader Technology
13 December 2003 3000021
Cable Pinouts
for PF PRO/ PF
Advantage
PN 3000477
CONXALL
Connector
SIGNAL COLOR HDB15
Connector
DUETCH
2-Pin
RADAR
1 TXDA RED 14
2 RXDA BLACK 13
3 GND GREEN 5 WHITE 2
4 BOOT BROWN CUT
5 RADAR BLUE N.C. BLACK 1
6 +12V WHITE 10
7 GND ORANGE 11
Cable
Pinouts
for Mobile
Logging
PN
3000475
CONXALL
Connector
SIGNAL COLOR DB9
Connector
DUETCH
2-Pin
RADAR
CIGARETTE
Plug
1 TXDA RED 2
2 RXDA BLACK 3
3 GND GREEN 5 WHITE 2
4 BOOT BROWN CUT
4 RADAR BLUE BLACK 1
6 +12V WHITE WHITE 1
7 GND ORANGE BLACK 2
