GPS 1000 Plus Radar Speed Simulation
Ag Leader Technology
11 December 2003 3000021
Radar Speed The GPS 1000 Plus is capable of outputting a simulated radar speed
pulse. This simulates a similar pulse output that you would receive from
a standard radar gun. The GPS 1000 Plus provides the capability to
provide simulated radar speed to your YM2000, PF3000, PF3000 Pro, PF
Advantage, or Insight display. To use the radar speed input with an Ag
Leader display, you must set the speed input to RADAR under the
appropriate setup screen for the monitor/display. Additional cables will
also be required to obtain the simulated speed output. Contact Ag
Leader’s Technical support team for these additional cables.
Radar Speed
Compatibility
Adaptor cables are available through Ag Leader Technology for the
following three radar gun brands Dickey-John, Raven, and Hiniker.
These adaptor cables provide the ability to use the GPS 1000 Plus in
place of a radar gun. If using the GPS 1000 Plus as a stand-alone
antenna, you will need to obtain an Auxiliary Power/Data Cable, GPS
power supply cable listed on page 15, and the appropriate Radar Speed
Adaptor Cable.
Radar Speed
Default Settings
The default output parameter provided in the GPS 1000 Plus is a
minimum output speed of .5 MPH, meaning speed pulses will not be
output below this speed. The default radar pulse output rate is 45 Hz per
MPH.
Radar Speed Adaptor Cable Name Part Number
Hiniker adaptor cable 3000498
Raven adaptor cable 3000479
Dickey John adaptor cable 3000480
