4 PN 2006346 Rev A
3. Mark the mounting hole centers on the mounting surface.
4. Place the receiver over the marks to ensure the planned hole centers align with the true hole centers
(adjusting as necessary).
5. Use a center punch to mark the hole centers.
6. Drill the mounting holes with a 9 mm bit appropriate for the surface.
7. Place the receiver over the mounting holes and insert the mounting screws through the bottom of the
mounting surface into the receiver.
Pole Mount
The center thread on the bottom of the receiver is 1”. The mounting assembly included with the receiver
includes an 5/8” adapter compatible with common survey poles. Simply thread the riser/pole into the
antenna until snug.
P
OWERING THE
R
ECEIVER
P
OWER
C
ONSIDERATIONS
The receiver accepts an input voltage of 7-32 VDC. For best performance use a clean and continuous
power supply. See
“Table B-4: Power Specifications” on page 9 for complete power specifications.
C
ONNECTING TO A
P
OWER
S
OURCE
The receiver uses a single cable for power and data input/output.
The antenna end of the cable is terminated with an environmentally sealed 12-pin connection and the
opposite end is DB9.
The receiver features reverse polarity protection to prevent excessive damage if the power leads are
accidentally reversed. With the application of power, the receiver automatically proceeds through an
internal startup sequence; however, it is ready to communicate immediately.
C
ONNECTING TO
E
XTERNAL
D
EVICES
Power/data port pinouts
IMPORTANT
Hand tighten only. Damage resulting from over-tightening is not covered by the warranty.
IMPORTANT
Hand tighten only. Damage resulting from over-tightening is not covered by the warranty.
IMPORTANT
Do not apply a voltage higher than 32 VDC. This will damage the receiver and void the
warranty.
