8 PN 2006346 Rev A
1600 R ECEIVER A
PPENDIX
B: T
ECHNICAL
S
PECIFICATIONS
Table B-1 through Table B-6 provide the GPS sensor, horizontal accuracy, L-band sensor,
communication, power, environmental, and mechanical specifications for the receiver.
T
ABLE
B-1 GPS S
ENSOR
S
PECIFICATIONS
Item Specification
Receiver type • L1 GPS
Channels
• 12 L1CA GPS
• 12 L1P GPS
• 3 SBAS or 3 additional L1CA GPS
GPS sensitivity • -142 dBm
SBAS tracking • 3-channel, parallel tracking
Update rate • 10 Hz standard,
Timing (1PPS) accuracy: • 20 ns
Cold start • < 60 s typical (no almanac or RTC)
Warm start • < 30 s typical (almanac and RTC)
Hot start • < 10 s typical (almanac, RTC, and position)
Maximum speed • 1,850 kph (999 kts)
Maximum altitude • 18,288 m (60,000 ft)
T
ABLE
B-2: H
ORIZONTAL
A
CCURACY
Item Specification
RMS (67%) 2DRMS (95%)
SBAS (WAAS)1 0.3 m 0.6 m
Autonomous, no SA1 1.2 m 2.5 m
