T
ABLE
B-3: C
OMMUNICATION
S
PECIFICATIONS
Item Specification
Serial 2 full-duplex RS-232, CAN
Baud rates 4800 - 115200
Data I/O protocol
NMEA 0183, NMEA 2000*, Hemisphere GPS binary 
*To use the receiver in a NMEA 2000 network requires NMEA
certification and a NMEA2000 adapter cable
Timing output 1 PPS CMOS, active high, rising edge sync, 10 kW, 10 pF load
Event marker input CMOS, active low, falling edge sync, 10 kW, 10 pF load
T
ABLE
B-4: P
OWER
S
PECIFICATIONS
Item Specification
Input voltage • 7- 32 VDC with reverse polarity operation
Power consumption • < 3 W @ 12 VDC typical
Current consumption • 134 mA @ 12 VDC typical
Power isolation • No
Reverse polarity protection • Yes
Antenna voltage • Internal antenna
T
ABLE
B-5: E
NVIRONMENTAL
S
PECIFICATIONS
Item Specification
Operating temperature • -40° C to +70° C (-40° F to +158° F)
Storage temperature • -40° C to +85° C (-40° F to +185° F)
Humidity • 95% non-condensing
Shock and Vibration
• Mechanical Shock: EP455 Section 5.14.1 Operational Vibration:
EP455 Section 5.15.1 Random
EMC
• CE (ISO 14982 Emissions and Immunity), FCC Part 15, Subpart B,
CISPR 22
Enclosure • IP67
