Part No. 2002831-42 Rev. C 8
Section 5: Key Settings/Functionality
Strip Till Application Rate Control Tab
The Application Tab shown at
left is a typical configuration
for a Strip Till module.
Press to display the Strip Till
window and settings.
Displays active swath width.
The Auto Swath check box
allows the enable/disable of
the Automatic Swath Control
functionality.
Displays the status of the
product control channel. When
the fertilizer bin is grey no
product application is taking
place. When product is being
applied, the fertilizer bin icon
will turn green.
Displays the current target
application rate. Press the up
arrow button to go to the
Target Rate Application
window.
