Ag Leader InSight Strip-Till - Manual (Page 2)

Part No. 2002831-42 Rev. C 2
Strip-Till Configuration (for multiple products)
STEPS ACTION
7 Enter Number of Boom Sections
Use the up and down arrow keys to enter the number of sections of the implement. Press
Next to continue.
8 Enter Boom Section Widths from Left to Right
For implements with more than one boom section, the system will default to the appropriate
number of equal width boom sections. To edit any of the boom values, select the desired
section from the list and press the numeric keypad to enter in a new width. Press Next to
continue.
9 Enter Distance from Hitch to Application Point
Enter the distance from the hitch to the application point (from front to back) using the
numeric keypad. Press Next to continue.
10 Implement Setup Wizard
Press Next to continue.
11 Enter Implement Name
Use the keyboard button to enter a name for the implement. Press Finish
12 Select Operating Mode
Use the drop-down menu to select Rate Logging/Control; then press Next.
13 Select Controller
Press the New button to add a controller; then press Next
14 Select Controller Device and Device Type
Select DirectCommand from the Device drop-down list box. Scroll down on the Direct
Type list box and select Granular Strip-Till Control. Press Next to continue.
15 Select Controller Device and Device Type
Select DirectCommand from the Device drop-down list box. Scroll down on the Direct
Type list box and select Granular Strip-Till Control. Press Next to continue.
16 Enter Suggested Controller Name
A default name of DirectStripTill appears. Press Finish, or use the on-screen keyboard to
enter a new name, if desired
17 Select Controller Channel
Use the drop-down menu to select a controller channel, then press Next to continue.
18 Select Container
Use the drop-down menu to select a container, or press the New button to enter a new
container; then press Next to continue.
