XP Performance Control user guide 59
PortWWN
[[port-name]:[port-name]][...]|
LU
[[port-name.host-group-id]:[port-name.host-group-id]][...]|
PPCG
[[PFC-group-name]:[PFC-group-name]][...]|
PPCGWWN
[[PFC-group-name]:[PFC-group-name]][...]|
RemoteCopy
|
RCLU
[port-name.host-group-id]:[port-name.host-group-id]][...]|
RCLDEV
[[CU-id]:[CU-id]][...]|
RCCLPR
|
UniversalReplicator
|
URJNL
[[JNL-group-id]:[JNL-group-id]][...]|
URLU
[port-name.host-group-id]:[port-name.host-group-id]][...]|
URLDEV
[[CU-id]:[CU-id]][...]
}
Description
The group subcommand specifies the type of monitoring data you want to export. This command uses an
operand (such as PhyPG and PhyLDEV above) to specify the type of monitoring data.
Table 24 shows monitoring data that can be saved into files by each operand, and the saved ZIP files.
For details on the monitoring data saved in these files, see the tables indicated in the See column.
Table 24 Operands of the group subcommand and saved monitoring data
Operand XP Auto LUN
Pane
Monitoring data saved in
the file
Saved ZIP file See
PhyPG
Physical tab in the
XP Auto LUN pane
Usage statistics about parity
groups
PhyPG_dat.ZIP
1 Table 3
PhyLDEV
Usage statistics about logical
volumes
PhyLDEV_dat.ZIP
1
PhyExG
Usage conditions about
external LU groups
PhyExG_dat.ZIP
PhyExLDEV
Usage conditions about
external LUs
PhyExLDEV_dat.ZIP
PhyProc
Usage statistics about
channel processors, disk
processors, and data
recovery and reconstruction
processors
PhyProc_dat.ZIP
1
PhyCSW
Usage statistics about access
paths and write pending rate
PhyCSW_dat.ZIP
1
PG
LDEV tab in the XP
Auto LUN pane
Statistics about parity,
external LU, or V-VOL groups
PG_dat.ZIP
Table 4
LDEV
Statistics about logical
volumes in parity, external
LU, or V-VOL groups
LDEV_XXXXX.ZIP
2 Table 5
Port
Port-LUN tab in the
XP Auto LUN pane
Statistics about ports
Port_dat.ZIP
Table 6
PortWWN
Statistics about host bus
adapters connected to ports
PortWWN_dat.ZIP
Table 7
LU
Statistics about LU paths
LU_dat.ZIP
Table 8
