HP StorageWorks XP Remote Web Console Software - Manual (Page 39)

XP Performance Control user guide 39
NOTE:
•
The letters xx in the CSV filename indicate the name of a PFC group.
• If files are exported to a Windows computer, CSV filenames may end with numbers (for example,
PPCGWWN_mygroup_IOPS-1.csv
and
PPCGWWN_MyGroup_IOPS-2.csv
).
Table 10 Files containing statistics on host bus adapters belonging to PFC groups
ZIP file CSV file Data saved in the file
PPCGWWN_dat.ZIP PPCGWWN_xx_IOPS.csv
I/O rate (that is, number of read and
write operations per second) for HBAs
belonging to PFC group
PPCGWWN_xx_KBPS.csv
Transfer rate for HBAs belonging to an
PFC group (unit is KB/sec)
PPCGWWN_xx_Response.csv
Average response time of HBAs
belonging to a PFC group (unit is
microseconds 1 )
1. 1 microsecond is one-millionth of 1 second
PPCGWWN_NotGrouped_IOPS.csv
I/O rate (that is, number of read and
write operations per second) for HBAs
that do not belong to any PFC group
PPCGWWN_NotGrouped_100KBPS.csv
Transfer rate for HBAs that do not belong
to any PFC group (the unit is KB/sec)
PPCGWWN_NotGrouped_Response.csv
Average response time of HBAs that do
not belong to any PFC group (unit is
microseconds 1 )
