34 XP Performance Control Export Tool
PhyExLDEV_dat.ZIP PHY_ExLDEV_Response_x-y.csv
Average response time time for logical
volumes in an external LU group (in
microseconds 1 )
PHY_ExLDEV_Trans_x-y.csv
Amount of data transferred for logical
volumes in an LU volume group (in
KB/sec)
PhyProc_dat.ZIP PHY_Long_CHP.csv
Usage rates for channel processors in
long range
PHY_Short_CHP.csv
Usage rates for channel processors in
short range
PHY_Long_DKP.csv
Usage rates for disk processors in long
range
PHY_Short_DKP.csv
Usage rates for disk processors in short
range
PHY_Long_DRR.csv
Usage rates for DRRs (data recovery and
reconstruction processors) in long range
PHY_Short_DRR.csv
Usage rates for DRRs (data recovery and
reconstruction processors) in short range
PhyCSW_dat.ZIP PHY_Long_MPA_CSW.csv
• Usage rates for access paths between
channel adapters and cache
memories in long range
• Usage rates for access paths between
disk adapters and cache memories in
long range
PHY_Short_MPA_CSW.csv
• Usage rates for access paths between
channel adapters and cache
memories in short range
• Usage rates for access paths between
disk adapters and cache memories in
short range
PHY_Long_MPA_SMA.csv
• Usage rates for access paths between
channel adapters and shared
memory in long range
• Usage rates for access paths between
disk adapters and shared memory in
long range
PHY_Short_MPA_SMA.csv
• Usage rates for access paths between
channel adapters and shared
memory in short range
• Usage rates for access paths between
disk adapters and shared memory in
short range
PHY_Long_CSW_CMA.csv
Usage rates for access paths between
cache switches and cache memories in
long range
PHY_Short_CSW_CMA.csv
Usage rates for access paths between
cache switches and cache memories in
short range
PHY_Long_Write_Pending_Rate.csv
Write pending rates in long range
PHY_Short_Write_Pending_Rate.csv
Write pending rates in short range
1. 1 microsecond is one--thousandth of 1 second.
Table 3 Files containing statistics on resource usage and write pending rates (continued)
ZIP file CSV file Data saved in the file
