XP Performance Control user guide 33
LDEV tab in the XP Auto
LUN pane
Statistics about parity groups, external LU groups, or V-VOL groups Table 4
Statistics about logical volumes in parity groups, in external LU
groups, or in V-VOL groups
Table 5
Port-LUN tab in the XP
Auto LUN pane
Statistics about ports Table 6
Statistics about host bus adapters connected to ports Table 7
Statistics about LU paths Table 8
WWN tab in the XP Auto
LUN pane
Statistics about PFC groups Table 9
Statistics about host bus adapters belonging to PFC groups Table 10
Cnt Ac Monitor pane and
TCz Monitor pane
Statistics about remote copy operations by XP Continuous Access
and TrueCopy for z/OS (in the whole array)
Table 11
Statistics about remote copy operations by XP Continuous Access
and TrueCopy for z/OS (at LU paths)
Table 12
Statistics about remote copy operations by XP Continuous Access
and TrueCopy for z/OS (at logical volumes controlled by a
particular CU)
Table 13
Statistics about remote copy operations by XP Continuous Access
and TrueCopy for z/OS (at CLPR)
Table 14
Cnt Ac-J Monitor pane
and URz Monitor pane
Statistics about remote copy operations by XP Continuous Access
Journal and Universal Replicator for z/OS (at CLPR)
Table 15
Statistics about remote copy operations by XP Continuous Access
Journal and Universal Replicator for z/OS (at journal groups)
Table 16
Statistics about remote copy operations by XP Continuous Access
Journal and Universal Replicator for z/OS (at LU paths)
Table 17
Statistics about remote copy operations by XP Continuous Access
Journal and Universal Replicator for z/OS (at logical volumes
controlled by a particular CU)
Table 18
Table 3 Files containing statistics on resource usage and write pending rates
ZIP file CSV file Data saved in the file
PhyPG_dat.ZIP PHY_Long_PG.csv
Usage rates for parity groups in long
range
PHY_Short_PG.csv
Usage rates for parity groups in short
range
PhyLDEV_dat.ZIP PHY_Long_LDEV_x-y.csv
Usage rates for logical volume in parity
group in long range
PHY_Short_LDEV_x-y.csv
Usage rates for logical volumes in parity
group in short range
PhyExG_dat.ZIP PHY_ExG_Response.csv
Average response time for external
volume groups (in milliseconds 1 )
PHY_ExG_Trans.csv
Amount of transferred data for external
LU groups (in KB/sec)
Table 2 XP Auto LUN panes and monitoring data that can be saved by the Export Tool (continued)
Pane Monitoring data See
