22 Using XP Performance Control
4. Select Change WWN & PFC Name. The Change WWN and PFC Name dialog box appears.
Figure 13 Change WWN and PFC Name dialog box
5. Enter a new PFC name (up to eight characters) in the PFC Name box, and click OK.
6. In the XP Performance Control pane, click Apply. Settings in the pane are applied to the array.
Replacing host bus adapters (many-to-many connections only)
If a host bus adapter fails, replace the adapter with a new one. After you finish the replacement, delete
the old host bus adapter from the XP Performance Control pane, and register the new host bus adapter.
Use the following procedure to quickly and easily remove the old adapter and register a new one.
1. Start XP Performance Control (” Starting XP Performance Control ” on page 15). The XP Performance
Control pane appears.
2. Click WWN.
3. In the upper-left tree view, click the old host bus adapter ( ) below the Monitor branch, and
right-click the selection.
4. Select Change WWN & PFC Name. The Change WWN and PFC Name dialog box appears
( Figure 13 ).
5. Enter the WWN of the new host bus adapter in the WWN box.
6. If necessary, enter a new PFC name (up to eight characters) in the PFC Name box.
7. Click OK.
8. In the XP Performance Control pane, click Apply. Settings in the pane are applied to the array.
Grouping host bus adapters
Use XP Performance Control to create a PFC group that contain multiple host bus adapters. All host bus
adapters (HBAs) in one PFC group must be of the same priority. Prioritized WWNs (for example,
high-priority HBAs) and non-prioritized WWNs (for example, low-priority HBAs) cannot be mixed in one
PFC group.
You can use a PFC group to switch the priority of multiple HBAs from prioritized to non-prioritized, or vice
versa. You can also use a PFC group to set the same upper limit value to all HBAs in the group.
Adding multiple HBAs to a PFC group
1. Start XP Performance Control (” Starting XP Performance Control ” on page 15). The XP Performance
Control pane appears.
2. Click WWN.
3. In the lower-left tree view, right-click the Subsystem folder.
4. Select Add New PFC Group. The Add New PFC Group dialog box appears.
Figure 14 Add New PFC Group dialog box
