HP Optical Jukeboxes - Manual (Page 18)

1-6 Chapter 1
Setting up the Jukebox
Removing the Mailslot Shipping Bracket and Checking Removal of the
Shipping Screw
Removing the Mailslot Shipping Bracket and
Checking Removal of the Shipping Screw
The jukebox is shipped with a plastic bracket inserted into the mailslot
to prevent damage to the mailslot during shipping. A shipping screw is
installed through the bottom of the chassis to restrain the cartridge
picker.
To remove the mailslot bracket, do the following. Refer to Figure 1-2.
1. Grasp both sides of the bracket and at the same time hook your
fingers underneath its lower edge.
2. Gently bend the bottom of the bracket out slightly and while jiggling
the bracket, pull it out from the mailslot.
Figure 1-2 The Mailslot Shipping Bracket
