HP ProLiant ML570 G4 Server - Manual (Page 72)

Hardware options installation 72
Removing the cable management arm
Pull the release pin and slide the cable management arm out from the inner rail.
Removing the server from the rack
WARNING: The server is very heavy, up to 63.5 kg (140 lb). To reduce the risk of
personal injury or damage to the equipment:
• Remove all power supplies and hard drives to reduce the weight of the server before
lifting it.
• Observe local occupational health and safety requirements and guidelines for manual
material handling.
• Use more than one person to lift and stabilize the server.
1. Extend the server on the rack rails until the server rail-release latches engage.
NOTE: The release latches will lock into place when the rails are fully extended.
2. Pull the server rail-release latches and extend the server until the server is free from the rack.
