Hardware options installation 53
11. Move the locking switch to the locked position.
12. Configure the memory (" Configuring the memory " on page 53 ).
13. Install the access panel (on page 27 ).
14. Do one of the following:
— Install and lock the bezel.
— Slide the server back into the rack.
Configuring the memory
Configuring the memory system of the server requires configuring both hardware and software.
To configure the memory:
1. Install the correct amount of memory for the desired AMP mode. For a list of AMP options, refer to
"Memory Options (on page
43 , " Single- and Dual-rank DIMMs " on page 44 )." For more
information, refer to "General Memory Configuration Requirements (on page 43 )."
2. Test the DIMMs for all AMP modes, except Advanced ECC, before configuring the AMP mode in
RBSU. The two testing methods are:
• POST memory test (on page 53 )
• ROM-Based Diagnostics test (" ROM-based diagnostics " on page 54 )
NOTE: If the total amount of memory has changed, the POST Memory Test will run automatically.
Additional memory testing is not necessary.
3. Select the AMP mode (" Selecting the AMP mode " on page 54 ).
POST memory test
1. Power on the server (" Power up the server " on page 23 ).
2. Press the F9 key, when prompted, to enter RBSU.
3. Select Advanced Options.
4. Change POST Speed Up to Disable.
5. Press any key to return to the RBSU main menu.
6. Press the F10 key, when prompted, to exit RBSU. The server reboots and tests all memory in the
system.
