Component identification 18
Item Description Status
3 Locking switch —
4 Removable Green = OK to remove the board
Off = Do not remove if the system is on
5 DIMM 1 LED Green = DIMM installed
Amber = Failed or degraded DIMM
Flashing amber = DIMM configuration error
Off = No DIMM installed
6 DIMM 2 LED Green = DIMM installed
Amber = Failed or degraded DIMM
Flashing amber = DIMM configuration error
Off = No DIMM installed
7 DIMM 3 LED Green = DIMM installed
Amber = Failed or degraded DIMM
Flashing amber = DIMM configuration error
Off = No DIMM installed
8 DIMM 4 LED Green = DIMM installed
Amber = Failed or degraded DIMM
Flashing amber = DIMM configuration error
Off = No DIMM installed
9 DIMM 5 LED Green = DIMM installed
Amber = Failed or degraded DIMM
Flashing amber = DIMM configuration error
Off = No DIMM installed
10 DIMM 6 LED Green = DIMM installed
Amber = Failed or degraded DIMM
Flashing amber = DIMM configuration error
Off = No DIMM installed
11 Online spare LED Green = Online spare mode
Amber = Degraded online spare mode
Flashing amber = Invalid AMP mode*
Off = Not in Online Spare mode
12 Hot-plug mirrored
LED Green = Mirrored mode
Amber = Degraded mirrored mode
Flashing amber = Invalid AMP mode*
Off = Not in Mirrored mode
13 Hot-plug RAID LED Green = RAID mode
Amber = Degraded RAID mode
Flashing amber = Invalid AMP mode*
Off = Not in RAID mode
