Scripting, command line, and utility options 124
-V—This switch is optional and sets the HPQLOMGC to Verbose mode.
-L —This switch defines where the log file is generated. This switch causes an error if
an IP address is not designated.
-Q—This switch is optional and sets the HPQLOMGC to Quiet mode.
7. Click Next. A screen is displayed with options for naming the task, defining the query association,
and setting a schedule for the task.
8. Enter a task name in the Enter a name for this task field.
9. Select the query that had been created earlier, for example "Mgmt Processors."
10. Click Schedule to define when the Application Launch task will run. A schedule configuration
window is displayed.
11. Click OK to set the schedule.
NOTE: The default schedule for a control task is Now.
12. Click Finish to save the Application Launch task.
13. Click the Execute a Task icon (the green triangle) to execute the Group Administration.
HPQLOMGC command language
When using HPQLOMGC, the directory settings for the management processor are read from an XML
file. The script used is a subset of the RIBCL and has been extended to support multiple management
processor firmware images. For more information concerning RIBCL for your management processor, refer
to the RILOE, RILOE II, or iLO user guide.
The following is an example of an XML file:
