HP NetRAID 1 Controller User Manual
Page 70
66
Signal
Connector Pin
Cable Pin
Cable Pin
Connector Pin
Signal
TERMPWR
18
35
36
52
TERMPWR
RESERVED
19
37
38
53
Reserved
GROUND
20
39
40
54
GROUND
GROUND
21
41
42
55
-ATN
GROUND
22
43
44
56
GROUND
GROUND
23
45
46
57
-BSY
GROUND
24
47
48
58
-ACK
GROUND
25
49
50
59
-RST
GROUND
26
51
52
60
-MSG
GROUND
27
53
54
61
-SEL
GROUND
28
55
56
62
-C/D
GROUND
29
57
58
63
-REQ
GROUND
30
59
60
64
-I/O
GROUND
31
61
62
65
-dB(8)
GROUND
32
63
64
66
-dB(9)
GROUND
33
65
66
67
-dB(10)
GROUND
34
67
68
68
-dB(11)
High-Density 68-Pin SCSI Connector Definitions
