HP StorageWorks Simple SAN Connection Manager user guide 33
Help menu
Table 6 provides a brief description of the items on the Help menu and a reference to more detailed
information.
Toolbar
The Simple SAN Connection Manager toolbar provides buttons for easy access to some of the
application’s most used functions, as well as information about the application. Table 7 shows each of the
toolbar buttons and what they do.
Get Network Properties Displays network information. “Viewing network properties”
on page 50.
Set Switch IP Address Changes the switch IPv4 or IPv6 address. “Setting the switch IP
address” on page 55.
Set Switch IPsec
Information
Manages a list of IP security associations
and policies.
“Setting switch IP security” on
page 64
Update Switch Firmware Updates the switch with a new firmware
image file.
“Updating switch firmware”
on page 57.
Set Switch Symbolic Name
and/or Domain ID
Changes the symbolic name and domain ID
for the switch.
“Setting the switch symbolic
name and domain ID” on
page 62.
Set Switch HBA-based
Default Zoning
Sets a switch default zone and includes or
excludes a device from a zone.
“Setting the switch default
zoning” on page 53.
Set Switch SNMP
Properties
Defines how authentication traps are
managed and set for the switch.
“Setting switch SNMP
properties” on page 59.
Set DNS Properties Enables or disables the DNS client on the
switch, and configures DNS on the switch.
“Setting DNS properties” on
page 62
Table 5 HBA & Switch Management menu (continued)
Menu Item Purpose See
Table 6 Help menu
Menu Item Purpose See
Contents Opens the Simple SAN Connection
Manager help system.
“Using the help system” on
page 34.
About the application Opens the About box that shows the version
of Simple SAN Connection Manager
installed, and the hardware and software
provider list.
—
Table 7 Toolbar buttons
Button Purpose
Create a logical disk
Assign a logical disk to a server
Expand a logical disk
