Option ROM Configuration for Arrays Utility 4-5
Compaq Confidential – Need to Know Required
Writer: Cynthia Dresden Project: Compaq Integrated Smart Array Controller User Guide Comments:
Part Number: 153236-001 File Name: e-ch4 Option ROM Configuration for Arrays Utility.doc Last Saved On: 9/1/99 2:13 PM
View/Delete Logical Drive Screen
The View/Delete Logical Drive screen allows you to delete the logical drive.
This screen appears when only one logical drive is configured.
Option ROM Configuration for Arrays, version x.x
Copyright 1999, COMPAQ Computer Corporation
Compaq Integrated Smart Array Controller
Detected Logical Drive Configuration
8.6GB RAID 5 drive, fault tolerant with online spare
Physical Drives Assigned
Online Spare
SCSI Port 2: ID 03, COMPAQ AB00411792 4.3GB Drive
Press to delete the logical drive configuration
Press to exit
Figure 4-4. View/Delete Logical Drive screen
NOTE: The logical drive configuration shown on your View/Delete Logical Drive screen
reflects the actual drives that are available on your system.
Pressing F3 deletes all settings, exits the Option ROM Configuration for
Arrays utility, and continues the POST and reboot process. To reconfigure the
Integrated Smart Array Controller, start the Option ROM process from the
beginning or initiate the Array Configuration Utility according to the
instructions for your operating system listed in Chapter 6 of this guide.
SCSI Port 2: ID 00, COMPAQ AB00911790 4.3GB Drive
SCSI Port 2: ID 01, COMPAQ AB00911790 4.3GB Drive
SCSI Port 2: ID 02, COMPAQ AB00911790 4.3GB Drive
