Starter Calibration Parameters
DD Discs
Disc Calibration Number
DD 30-030673 1.75
Parameters Default Units Description
1 Additive % Percent Using the arrow keys, set additive ratio.
2 Shot size of the current mold Grams/pounds Using the arrow keys, set the shot size of the current capacity in grams/min or pounds/min.
3 Screw recovery time Seconds Using the arrow keys, set the screw recovery time (in seconds)
4 Calibration weight for additive Grams Enter a value from the tables below and proceed to calibration mode to set the calibration value.
18 Totalizer (display only) Grams/pounds
Digital Dosing unit parameter setup 1-4 for extrusion - contant
Parameters Default Units Description
1 Additive % Percent Using the arrow keys, set additive ratio.
2 throughput Grams/pounds Using the arrow keys, set to the throughput of the extruder capacity in grams/min or pounds/min
3 Not used
4 Calibration weight for additive Grams Enter a value from the tables below and proceed to calibration mode to set the calibration value.
18 Totalizer (display only) Grams/pounds
