Digital Dosing Units 52
16. Mount the safety screws.
17. Install the dosing container along with the dosing hopper on the dosing housing
(pay attention to the guide pins).
18. Mount the profile clamp.
19. Mount the screw at the profile clamp and tighten.
5.7 Exchangeable Stations
Dosing discs of the same type may be exchanged for each other without any problems. If
dosing discs with a different compartment number are installed, this has to be entered in the
control system.
1. Enter the (preliminary) calibration value of the freshly installed dosing disc
DT Discs
Disc Calibration
Number
Number of
Pockets
DT 30-101820 32.00 20
DT 30-102025 38.00 25
DT 30-203012 100.00 12
DT 30-204010 175.00 10
DP Discs
Disc Calibration
Number
Number
of
Pockets
Disc
Thickness
DP 30-050940 17.00 40 0.5 mm
DP 30-250940 8.00 40 2.5 mm
2. Execute “calibration” to determine the final calibration value.
