Digital Dosing Units 10
Recipe Setup for Extrusion:
1. Turn power switch to ON position.
2. Press Input to display # 1, “Additive %”. Using arrow keys, set additive ratio.
3. Press Input to display # 2, “Throughput of extruder”. Using arrow keys, set the
total extruder throughput in g/min or lb/min.
4. Press Input to display # 3, “Extruder screw speed”. Using arrow keys, set the
extruder screw speed RPM expected during production.
NOTE: For Extrusion - Constant operation, the above step will be skipped.
5. Press Input to display # 4, “Calibration weight for additive”. Enter the appropriate value
from the range table on page 9 and proceed to calibration mode below for calibration
of additive material.
Calibration:
1. Press “Calibration” button to start this procedure. Display will show - - - -
2. Place the plastic calibration cup on the scale and tare so that the weight of the cup
(approx. 24 grams) is not calculated in the calibration procedure.
3. Remove cover of the calibration box, secured by two 5 mm Allen screws, under the
dosing disc assembly and insert plastic cup provided in top of dosing hopper.
4. Press “Run” and the dosing disc turns 1/4 turn. This fills all pockets of dosing
disc. Dump the dosed material back into the dosing hopper without weighing and
replace plastic cup in calibration box.
5. Press “Run” and the dosing disc turns 1 complete revolution. Remove the
calibration cup with the material and place on the gram scale. Enter the weight on the
scale into the controller using the arrow keys. Empty and replace calibration
cup.
6. Repeat step # 5 four more times, each time entering the new weight from the scale
into the controller using the arrow keys. Sometimes the values won’t change, or
sometimes they may only change by a few tenths of a gram. The controller keeps a
running average of all calibration weights entered.
