Heli-coil heat exchanger – Prochem Everest EFI User Manual
Page 80
HELI-COIL HEAT EXCHANGER
EVEREST EFI 980197 06/30/04
5-34
REF PART
NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1
70554
2
SCR, 3/8-16 X 3.5 HHCS GR5PLTD
2
87171
4
WASHER, 3/8 FLAT
3
790445
1
BRKT, RIGHT HOOD MTG
4 57-520073 1 HE,
HELI-COIL
5
15-808073
1
COCK, DRN 1/4P X 1/4 HOSE ELL
6
57119
2
NUT, 3/8-16 HEX NYLOCK
7
03-000248
5
CLMP, HOSE #16 1-1/2 MIN 1-3/4
8 52-501627 1 INL,
HE
9
12-800326
2
ELL, 3/4P X 1/2T BR
10
790885
1
CASTING LWR RAD HOSE ZEEMS
11
01-000259
1
RECPT, SNAPIN 1/4 TURNFA
