UPHOLSTERY TOOL-OPTIONAL
EVEREST EFI 980197 06/30/04
5-64
REF PART
NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
-
78513
1
TL, UPHOLST, PC (80015)
COMPLETE
1
09-805131
2
HOSE, VAC 1-1/4X10’ BLU
2 08-805243 1 CUFF,
SWIV
1-1/4HX1-1/4T
3 10-805347 1 HOSE,
3/16X119-1/2
(1/8PX1/4FT)
4 13-806023 1 DSC,
1/8FC1/8FP
SST
5 58-500639 1 UPHOLSTERY
TL
TRIGGER
6
00-000310
1
SCR, CAP 4-40 X7/32 SHCS SS
7
04-000282
1
SPRING, VAC ADJ BUTT
8
52-501624
1
BUTTON, VAC ADJ
9 52-501842 1 TOOL,
UPHOLSTERY
10
61-950570
1
ASSY, UPHLST TL VLV
INCLUDES
PARTS
20-26, 28, & 31- 37
11 560012 1
NIPPLE,
1/4
NPT
QD
12
17-803010
1
CONN, 1/4P X 11/16-16M
13 17-803006 1 WASHER,
NYLON
14 14-806512 1 STRAIRNER,
JET
50MESH
15
17-803036
1
CONN, 1/4FPX11/16-16F BR
16 11-800404 1 NIP,
1/4X5
SST
17 52-501585 1 COUPLER,
UPHLST
TL
18
12-800065
1
CONN, 1/8P X 1/4T
19
08-805138
1
CUFF, 1 1/4H X 1 1/2T GRY
20
16-808229
1
HOLDER, VLV STEM-EXTRCTR VL
21
43-810063
1
O-RING, .551 ID .691 OD
22 16-808228 1 SEAT,
EXTRCTR
VLV
23 16-808189 1 STEM,
EXTRCTR
VLV
24 43-810064 1 BACK-UP,
250DIA
25
43-810062
1
O-RING, .144 ID .254 OD
26 16-808190 1 SPRING,
EXTRCTR
VLV
27
00-000306
2
SCR, 6-32 X 1 SCHD SS
28
17-803033
1
TIP, SPRY 80015X1/8P SST
29 58-500638 1 CSTG,
TRIGGER
CLMP
30
00-000307
2
SCR, CAP 6-32X3/8 SOCHD
31 52-501623 1 VALVE,
UPHLST
TL
32
52-501626
1
VALVE, ADJ-UPHLST TL VLV
33
43-810016
1
O-RING, 5/32IDX9/32OD VIT
34
43-807513
1
GASKET, UPHLST TL VLV
35
10-805348
1
HOSE, 3/16X6-1/2 (1/8P BS)
36 13-806030 1 DSC,
1/8MX1/8FP
SST
37
00-000408
1
SCR, SET 3-32 X 1/4 SOCHD
-
48-941164
1
DECAL, UPHLST TL
NOT SHOWN
-
66-808169
1
KIT, REPAIR-WAND VLV
NOT SHOWN
INCLUDES PARTS
20-22 & 24-26
