SHELF ASSEMBLY-OPTIONAL
EVEREST EFI 980197 06/30/04
5-66
REF PART
NO. QTY
DESCRIPTION
SERIAL NO.
FROM
NOTES:
-
65-950392
1
VAN STORAGE UNIT
COMPLETE
1 56-501921 1
SHELF,
LWR
2 02-000066 FLATWASHER,
1/4
3
87162
WASHER, 1/4 SPLIT LOCK
4
70721
SHOULDER BOLT, 182 OD X 2.25 L
5
70270
SCR, 1/4-20 X 3/4 HHCS PLTD
6
50-501840
1
BRKT, ADJUST MTG SLOT
7
56-502067
1
BRKT, ADJUST MTF HLDR
8 56-501942 1
BRKT,
SHELF
MOUNTING
9
50-501753
1
HOLDER, STAIR TOOL
10
01-000105
LOCK NUT, 1/4-20 HXHD
11 56-501922 2 PANEL,
SHLF
END
12 50-501749 WASHER,
NYLON
13 56-501920 1 DRAWER,
SHELF
GRAY
14
46-802506
1
LATCH, ADJ GRIP
15 50-501755 1 HOLDER,
UP
TO
HOSE
16 50-501754 1 HOLDER,
UPHST
TL
17 48-941152 1 DECAL,
PROCHEM
- 66-945424 1
KIT,
ADJ
BRKT.
INCLUDES PARTS 6,7 &
MOUNTING HARDWARE
