Vac/heat exchanger with silencer – Prochem Everest EFI User Manual
Page 76
VAC/HEAT EXCHANGER WITH SILENCER
EVEREST EFI 980197 01/06/05
5-30
REF PART
NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1
00-000078
22
SCR, 1/4-20 X 1” HXHD GRD8
2
70377
1
SCR, 3/8-16 X 1.25 HHCS GR5PLT
3
70069
4
SCR, 3/8-16 x 3 HHCS GR5
4
57119
11
NUT, 3/8-16 HEX NYLOCK
5
87162
22
WASHER, 1/4-20 SPLIT LOCK PLTD
6 02-000066 22 FLATWASHER,
1/4
7
87171
14
WASHER, 3/8 FLAT
8
11-800276
3
ELL, 3/8 BR
9
12-800282
4
CONN, 3/8P x 1/2T BR
10
12-800345
2
FTTG, BRB 3/8P x 5/8H BR
11
790050
3
GASKET, VAC HE CVR
12 790388 2
ASSEMBLY,
HEATER
CORE
13
790755
1
HSG, VAC HE
14
57111
2
MIT. 3/8-16 HEX
15
620023
2
PLT, HEATER CORE CVR, STL
16 790341 1
VAC
MUFFLER
17
36238
6
GROM, 1/2IDX1-1/4OD 1/8G 5/16W
18
790343
3
PAD, BTM VAC HTR CORE
19
790423
3
PAD, REAR VAC HTR CORE
20
790814
1
TUBE, EXHAUST ZEEMS
21
780800
2
GSKT, EXH, A-15 ZEEMS
22
70266
6
SCR, 3/8-16 X 1” HHCS GR5 PLTD
23
790039
1
GASKET, VAC HE BOX TO MUFFLER
24
790051
6
PLT, NUT-VAC HE HSG
25
790038
3
FORGING, HEATER CORE MANIFOLD
26
42-902415
1
GSKT, EXH, NIS 20691-72W00
27
11-800224
5
PLG, 3/8 SOCHD BR
28
12-800225
1
ELL, ST 3/8 P X 1/2T BR
29
00-000064
12
RIV, 1/8 x 3/8 ALUM
30
620024
1
PLT, HEATER CORE CVR FRONT, STL
31
50-502023
1
FLG, EXH NISSAN A-15
32 790505 1
ASSEMBLY,
HEATER
CORE (COPPER)
INCLUDES 17 & 30
33
790775
1
CONV, CAT, ZEEMS
34
87163
10
WASHER, 3/8 SPLIT LOCK PLTD
35
01-000296
3
NUT, EXH MNFLD, A-15
36 790891 1
O2
SENSOR
37
87083
3
WASHER, 5/16 SPLIT LOCK, PLTD
