Prochem Everest EFI - Manual (Page 106)

WAND - TRI-JET - OPTIONAL
EVEREST EFI 980197 06/30/04 5-60
REF PART NO. DESCRIPTION
SERIAL NO.
FROM
NOTES:
- 89233 WAND, TJW (9502) PC COMPLETE
- 89232 WAND, TJW, (95015) CUBXL COMPLETE
- 89234 WAND, TJW, (9503) PC COMPLETE
1 56012 NIPPLE, 1/4 FPT QD
2 17-503010 CONN, 1/4P X 11/16-16M
3 17-803006 WASHER, NYLON
4 14-806512 STRAINER, JET 50MESH
5 17-803036 CONN, 1/4FP,11/16-16R BR
6 56015 NIPPLE, 1/4 HEX
7 09-805359 SLEEVE, WD HDL 9.5
8 52-501619 TRIGGER, WD VLV
9 00-000317 SCR, CAP 10-32X 1-1/4 SOCH
10 57090 NUT, 10-32 HEX NYLOCK SS
11 61-950496 ASSY, EXTRCTR VLV
12 12-800060 CONN, 1/4P X 1/4T BR
13 10-805253 HOSE, 3/16X49 (1/8P X 1/4FT)
14 04-000053 TIE, CABLE 8” WHT
15 00-000282 SCR, CAP 1/4-20 X 1-1/4 SOC
16 52-501569 HOLD DOWN, WD HDL
17 52-501568 BODY, WD HDL
18 56-501712 WAND & HEAD, TRI-JET WD
19 17-803002 TIP, SPRY 9502X1/8P SST 89233
19A 17-803001 TIP, SPRY 9501X1/8P SST 89232
19B 17-803046 TIP, SPRY 9503X1/8P SST 89234
20 70162 SCR, 10-32 X 3/8 PPHMS SS
21 87165 WASHER, #10 SPLIT LOCK
22 57014 NUT, 10-32 HEX SS
23 56-501739 MANIFOLD, WD TRI-JET
24 11-800206 PLUG, 1/8 SOCHD BR
25 16-808229 HOLDER, VLV STEM-EXTRCTR VL
26 43-810063 O-RING, .551 ID .691 OD
27 16-808228 SEAT, EXTRCTR VLV
28 16-808189 STEM, EXTRCT VLV
29 43-810064 BACK-UP, .250DIA
30 43-810062 O-RING, .114ID .254OD
31 16-808190 SPRING, EXTRCTR VLV
32 52-501590 BODY, EXTRCTR VLV
- 48-941166 DECAL, WD HD NOT SHOWN
- 66-808169 KIT, REP-WD VLV
NOT SHOWN
INCLUDES PARTS 25-27
& 29-31
