WAND- TITANIUM SIX JET-OPTIONAL
EVEREST EFI 980197 12/27/06 5-56
REF PART NO. DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 00-000282 SCR, CAP 1/4-20 X 1 1/4 SOC
2 00-000317 SCR, CAP 10-32 X 1 1/4 SOCH
3 70228 SCR, 10-32 X 1/4 PPHMS SS
4 57090 NUT, 10-32 HEX NYLOCK SS
5 04-000093 TIE, CABLE 13”
6 09-805603 HOSE, INT VAC 4-1/2 X 48
7 10-805504 HOSE, 3/16 X 44-1/2
8 56015 NIPPLE, 1/4 HEX
9 11-800206 PLUG, 1/8 SOCHD BR
10 12-800060 CONN, 1/4P X 1/4T BR
11 12-800322 CONN, 1/8P X 1/4T COMP BR
12 56012 NIPPLE, 1/4 FPT QD
13 14-806512 STRAINER, JET 50 MESH
14 17-803018 TIP, SPRAY 9501 X 1/8P SST
15 17-803006 WASHER, NYLON
16 17-803010 CONN, 1/4P X 11/16-16M
17 17-803036 CONN, 1/4FP X 11/16-16F BR
18 17-803078 TIP, SPRAY 8001 SST 1/8 VJET
19 52-501619 TRIGGER, WD VALVE
20 52-502008BK BODY, WD HDL, 2” TB, BK
21 52-502009 HOLD DN-WD HDL 2” TUBE
22 52-502057 MANFOLD, LEFT
23 52-502058 MANIFOLD, RIGHT
24 56-502548 ASSY, MNFLD S-BEND
25 56-502534 WD & HD, TITANIUM
26 61-950496 ASSY, EXTRACTOR VALVE
27 16-808189 STEM, EXTRACTOR VALVE
28 16-808190 SPRING, EXTRACTOR VALVE
29 16-808228 SEAT, EXTRACTOR VALVE
30 16-808229 HLDR, VLV STEM-EXTRACTOR VL
31 43-810062 O-RING, .114 ID .254OD
32 43-810063 O-RING, .551ID .691OD
33 43-810064 BACK-UP, .250DIA
34 52-501590 BDY, EXTRACTOR VLV
35 48-941462 DEC, WD HD TITANIUM
- 48-941296 BLB, INSPECTION QC (PINK)
