HOSE REEL-OPTIONAL
EVEREST EFI 980197 06/30/04
5-72
REF PART
NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1
56-501962
1
REEL, VACUUM HOSE GRAY
2
03-000124
2
CLAMP, MFLR 1-3/4
3
52-501685
2
BUSHING, HOSE REEL
4
56-501960
1
BASE, HOSE RL (250’)
5
56-502207
1
BRKT, LOCKOUT HOSE REEL
6 61-950854 1 LATCH
ASSEMBLY
7 02-000066 2 FLATWASHER,
1/4
8
87162
2
WASHER, 1/4 SLPIT LOCK
9
70270
2
SCR, 1/4-20 X 3/4 HHCS PLTD
10
57031
2
NUT, 5/16-18 HEX
11
56-501968
1
REEL, HP HOSE GRAY
12 45-802138 2 BEARING
HOSE
REEL
13 02-000143 4 FLATWASHER,
5/16
14
87083
4
WASHER, 5/16 SPLIT LOCK PLTD
15
70302
4
SCR, 5/16-18 X 1” HHCSGR5PLT
16 44-802122 4 FLANGE,
47MST
17
56-501961
1
BODY, HP HOSE GRAY
18
00-000072
10
SCR, 3/8-16 X 2” HXHD
19
50-500511
1
PLATE, INSTALL MT
20
87171
10
WASHER, 3/8 FLAT
21 57119 10
NUT,
3/8-16
HEX
NYLOCK
22
55-501789
1
PIN, LOCK HOSE REEL
23 50-501812 1 BRKT,
HOSE
REEL
LOCK
24
04-000302
1
SPRING, LOCK-LOCK PIN ASSY
25
04-000303
1
CLIP, RETAINER-LOCK PIN ASSY
