VACUUM BLOWER
EVEREST EFI 980197 01/26/05
5-22
REF
PART NO.
QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1
57114
2
NUT, 7/16-14 HEX
2
87171
16
WASHER, 3/8 FLAT
3
04-000091
1
SPRING, VAC REL VLV
4
12-800099
2
ELL, 1/8P X 1/4 POLY BR
5
43-807106
1
DIAPH, VAC REL VLV
6 52-501684 1
ELL,
VAC
REL
VLV
7 56-501994 1
STM-VAC
REL
VLV
8 140611 1
BLWR,
TRI-FLOW
9 790842 1
PULLEY,
BLOWER
2TB52
10
790444
1
HUB, P1 X 1-1/4
11
52-502071
1
NIPPLE, VAC OUTL TRI-FLOW
12
43-810104
2
O-RING, 3-1/4 X 3-1/2 OD
13 790443 2
SPACER,
BLOWER
14 790442 1
PLT,
BLOWER
ADJUST
15
44-802319
2
BELT, BX46 GOODYEAR MATCH
16
790467
4
SCR, 5/16-18 X 1.25 SHCS
17
70377
4
SCR, 3/8-16 X 1.25 HHCS BR5PLT
18
87163
8
WASHER, 3/8 SPLIT LOCK
19
70069
4
SCR, 3-8-16 X 3 HHCS BR5
20
57119
4
NUT, 3/8-16 HEX NYLOCK
21
00-000336
2
SCR, CAP 3/8-16 X 3 ALL THD
22
57111
3
NUT, 3/8-16 HEX
23
00-000340
3
SCR, MACH 5/16-18 X 1” GR 8
