OPERATIONS
EVEREST EFI 980197 06/30/04 3-5
ERROR CODES
On rare occasions the engine may experience abnormal operation conditions and shut down. Upon shutdown the
amber light in the upper right corner of the instrument panel will repeatedly flash an error code to help you
determine the root cause of the shutdown. Double-digit numbers are flashed one digit at a time, (i.e. “12” would
be shown as “Flash”, pause, “Flash”, “Flash”). The codes are listed below for your convenience.
CONDITION SEQUENCE RESULT
TROUBLE
CODE
TROUBLE
FLAG
CODE/FLAG
RETAINED IN
MEMORY WITH
KEY OFF?
1
ENGINE OIL PRESSURE SWITCH
INDICATES LOW OIL PRESSURE OIL PRESSURE SWITCH INDICATES OIL PRESSURE
IS LOW FOR 1 COMPLETE SECOND - ENGINE
2 NO
1 RPM LIMITED TO 950 MAXIMUM FOR 60 SECONDS 3 NO
2
ONCE 60 SECOND TIME LIMIT IS EXCEEDED -
ENGINE SHUTDOWN OCCURS
3 NO
1 RPM LIMITED TO 950 MAXIMUM FOR 60 SECONDS 4 NO
2
ONCE 60 SECOND TIME LIMIT IS EXCEEDED -
ENGINE SHUTDOWN OCCURS
4 NO
4
BEGINNING OF DIAGNOSTIC
ROUTINE NO FAULT CONDITION EXITS - SIGNIFIES
BEGINNING OF FLASH CODES
12
YES-ALWAYS
PRESENT
1 TROUBLE CODE IS STORED IN MEMORY 14 3
CODE RETAINED
IN MEMORY
2 RPM LIMITED TO 950 MAXIMUM FOR 60 SECONDS 14 3
FLAG CLEARS
WHEN IGNITION
IS OFF
3
ONCE 60 SECOND TIME LIMIT IS EXCEEDED -
ENGINE SHUTDOWN OCCURS
14 3
FLAG CLEARS
WHEN IGNITION
IS OFF
6
ENGINE COOLANT SENSOR
INDICATES OPEN CIRCUIT
TROUBLE CODE IS STORED IN MEMORY 15
CODE RETAINED
IN MEMORY
7
PEDAL POSITION SENSOR OVER
VOLTAGE (OVER 4.5 VOLTS)
TROUBLE CODE IS STORED IN MEMORY 21
CODE RETAINED
IN MEMORY
8
PEDAL POSITION SENSOR
UNDER VOLTAGE (0 VOLTS)
TROUBLE CODE IS STORED IN MEMORY 22
CODE RETAINED
IN MEMORY
9
AIR TEMPERATURE SENSOR
INDICATES OPEN CIRCUIT
TROUBLE CODE IS STORED IN MEMORY 23
CODE RETAINED
IN MEMORY
10
AIR TEMPERATURE SENSOR
INDICATES SHORT CIRCUIT
TROUBLE CODE IS STORED IN MEMORY 24
CODE RETAINED
IN MEMORY
11
MAP SENSOR CIRCUIT
INDICATES HIGH VLOTAGE (4.98
TROUBLE CODE IS STORED IN MEMORY 33
CODE RETAINED
IN MEMORY
12
MAP SENSOR CIRCUIT
INDICATES SHORT TO GROUND
TROUBLE CODE IS STORED IN MEMORY 34
CODE RETAINED
IN MEMORY
13
OXYGEN SENSOR - LEAN
CONDITION DETECTED
TROUBLE CODE IS STORED IN MEMORY 44
CODE RETAINED
IN MEMORY
14
OXYGEN SENSOR - RICH
CONDITION DETECTED
TROUBLE CODE IS STORED IN MEMORY 45
CODE RETAINED
IN MEMORY
2
ENGINE OVERHEATING
DETECTED (COOLANT >= 239 F)
5
ENGINE COOLANT SENSOR
INDICATES SHORT CIRCUIT OR
EXTREME OVERHEATING OF
ENGINE (COOLANT TEMP >= 266
F)
3
TRANSMISSION OIL
TEMPERATURE SWITCH
INDICATES OVERTEMP
